The MySensors api handles most of the commuication in the background without much inferference needed from the sketch programmer. Let's start off with a little Sensor example.

Sensor Nodes

To create the Arduino program (also known as sketch) that reports sensor data over the air you only need to write a few lines of code. In the following example we assume you have a RF24 radio attached to the arduino and want to send some door status:

#define MY_RADIO_RF24

#include <MySensors.h>

#define OPEN 1
#define CLOSE 0
#define CHILD_ID 1

MyMessage msg(CHILD_ID, V_TRIPPED);

uint8_t value = OPEN;

void presentation()
{
  present(CHILD_ID, S_DOOR);
}

void loop()
{
  value = value == OPEN ? CLOSE : OPEN;
  send(msg.set(value));
  sleep(10000);
}

Ok! So, what is happening here?

Initialization

The MySensors library is automatically started and presents the node.

If this is the first time the node is started it will fetch a unique node-id from the controller.

Once an id has been received from the controller it will be saved in the Arduino's static EEPROM memory. The id is automatically read from EEPROM each time the Sensor node resets or powers-up.

The initialization also determines the shortest network path to the gateway.

In this example the #define MY_RADIO_RF24 determines which radio type you use.

Presentation

Your sensor must first present itself to the controller. The presentation is a hint to allow controller prepare for the sensor data that eventually will come. This is done by calling present(child-sensor-id,sensor-type)

sensor-type The list of supported sensor types is constantly growing. For a more in-depth sensor type explanation, refer to the sensor type tables.

All present() calls should be placed in the presentation()-function. The controller can later re-request this information from the node.

typedef enum {
    S_DOOR, S_MOTION, S_SMOKE, S_LIGHT, S_DIMMER, S_COVER, S_TEMP, ...
} sensor;

child-sensor-id Each radio node can report data for up to 254 different child sensors. You are free to choose the child id yourself. You should avoid using child-id 255 because it is used for things like sending in battery level and other (protocol internal) node specific information.

Sending Data introduction

To send data you have to create a MyMessage container to hold the information. Declaring a container looks like this:
MyMessage msg(child-sensor-id, variable-type);

In the loop() method of the example above we do the actual sending by calling send(msg.set(payload)). This is where the sensor data is transferred to the controller (or some other destination).

child-sensor-id This is where you specify the child sensor that's reporting the data. In the example we only have one child sensor so we pick 0.

variable-type When sending data to the controller you must specify what type of data you report. We call this the variable type. Often the sensor type and variable type is almost the same but there are a few sensors that report more than one variable type-value. For example; Power meters could report both the accumulated KWH and the current WATTAGE. The list of variable types is also growing. You can read the variable type table for more details.

typedef enum {
    V_TEMP, V_HUM, V_LIGHT, V_DIMMER, V_PRESSURE, V_FORECAST, V_RAIN, ...
} variableType;

You will always find the most recent list of supported sensor and variables-types in MyMessage.h on GitHub:

GitHub | MyMessage.h

The above example was intentionally simplistic and pointless because it only alternates OPEN/CLOSE value every 10 seconds. However, it should help you understand how to write a sensor sketch. There are plenty of more advanced examples here on MySensors if you enjoy copy-paste programming ;).

Create Repeating Nodes

If you live in a Faraday's cage or a huge mansion you might need a few repeater nodes to cover the full area. This is when the build-in repeater functionality comes in handy.

To turn a node into a repeater, you'll have to remember a couple of things:

  • Enable repeater-mode by defining the following at the top of the sketch:

      #define MY_REPEATER_FEATURE
  • Keep node awake all time (no sleeping!). This means a repeater can't be battery-powered.

  • The node must be able to process incoming messages (no long-running loops!). If you must run a loop, call wait() often.

Configuration

The configuration of the sketch is a very important step when building a MySensors node. It enables/disables features of the core at compile time and can be done directly in the sketch source using #define-statements.

The configuration file MyConfig.h contains many default values for the configuration value. It's pretty well documented and you can have a look at it here.
