C2 | 100n | C-EUC0805 | C0805 | CAPACITOR, European symbol | |
C4 | 100n | C-EUC0805 | C0805 | CAPACITOR, European symbol | |
C5 | 100n | C-EUC0805 | C0805 | CAPACITOR, European symbol | |
C6 | 100n | C-EUC0805 | C0805 | CAPACITOR, European symbol | |
C7 | 100n | C-EUC0805 | C0805 | CAPACITOR, European symbol | |
C8 | 100n | C-EUC0805 | C0805 | CAPACITOR, European symbol | |
C9 | 100n | C-EUC0805 | C0805 | CAPACITOR, European symbol | |
C10 | 100n | C-EUC0805 | C0805 | CAPACITOR, European symbol | |
C11 | 220u | CPOL-EUSANYO_SMD_C6 | SANYO-OSCON_SMD_C6 | POLARIZED CAPACITOR, European symbol | https://www.tme.eu/de/details/sc1a227m6l07kvr/elektrolytisch... |
R3 | 10k | R-EU_R0805 | R0805 | RESISTOR, European symbol | |
R7 | 56k | R-EU_R0805 | R0805 | RESISTOR, European symbol | |
R8 | 10k | R-EU_R0805 | R0805 | RESISTOR, European symbol | |
R9 | 10k | R-EU_R0805 | R0805 | RESISTOR, European symbol | |
R10 | 470k | R-EU_R0805 | R0805 | RESISTOR, European symbol | |
R11 | 1M | R-EU_R0805 | R0805 | RESISTOR, European symbol | |
RESET | | SPST.B3U-1000P(M) | B3U-1000P(M) | | https://www.tme.eu/de/details/b3u-1000pm/mikroschalter-tact/... |
S1 | | REED-SWITCH-MK6-5-C | MK6-5 | Reed Sensor | https://www.tme.eu/de/details/mk65g/reed-relais/meder/mk06-5... |
S2 | | REED-SWITCH-MK6-5-C | MK6-5 | Reed Sensor | https://www.tme.eu/de/details/mk65g/reed-relais/meder/mk06-5... |
U$1 | 8MHz | CSTCE | CSTCE | Murata CSTCE Resonator - 3,2 x 1,3 mm | https://www.tme.eu/de/details/cstce8m00g52a-r0/keramikfilter... |
U$2 | | NRF24SMD | NRF24SMD | | |
U1 | | ATMEGA328P-AU | | 8-bit Microcontroller with In-System Programmable Flash | http://www.tme.eu/de/details/atmega328p-au/mikrocontroller-a... |
U3 | | IC_ATSHA204A_CRYPT | SOT23-3 | | |
X1 | FTDI | | JST | | |
X2 | AVRISP | | JST | | |
Batt + | + | KEYSTONE 597 | | | https://www.tme.eu/de/details/keys597/batterien-behalter-und... |
