| | | 50 pcs | | | | | |
Reference | Quantity | Value | Footprint | Datasheet | Link | Mfr. NO | Supplier | |
C1 | 1 | 10uF; 25VDC; SMD;Case C; 2312; ±10% | Capacitor_Tantalum_SMD:CP_EIA-6032-20_AVX-F_Pad2.25x2.35mm_HandSolder | | | | - | |
C11 C12 | 2 | 22p COG +-5% | Capacitor_SMD:C_0805_2012Metric_Pad1.15x1.40mm_HandSolder | ~ | | | - | |
C13 C14 | 2 | 1nF; 50V; X7R; ±10% | Capacitor_SMD:C_0805_2012Metric_Pad1.15x1.40mm_HandSolder | ~ | | | - | |
C3 C2 C10 C9 C8 C5 | 6 | 100nF; 50V; X7R; ±10% | Capacitor_SMD:C_0805_2012Metric_Pad1.15x1.40mm_HandSolder | ~ | | | - | |
C4 | 1 | 10uF; 10VDC; SMD; Case A; 1206; ±20% | Capacitor_Tantalum_SMD:CP_EIA-3216-12_Kemet-S_Pad1.58x1.35mm_HandSolder | ~ | | | - | |
C6 | 1 | 10nF; 50V; X7R; ±10% | Capacitor_SMD:C_0805_2012Metric_Pad1.15x1.40mm_HandSolder | ~ | | | - | |
D3 D2 D1 | 3 | TS4148 | Diode_SMD:D_0805_2012Metric | | https://www.tme.eu/sk/details/ts4148-ryg/univerzalne-diody-s... | TS4148 RYG | - | |
D4 | 1 | Red | LED_SMD:LED_0805_2012Metric_Pad1.15x1.40mm_HandSolder | ~ | https://www.tme.eu/sk/details/lh-r974-lp-1/diody-led-smd-far... | LH R974-LP-1 | - | |
D5 | 1 | Grn | LED_SMD:LED_0805_2012Metric_Pad1.15x1.40mm_HandSolder | ~ | https://www.tme.eu/sk/details/el17-215sygc_53/diody-led-smd-... | EL17-215SYGC/53 | - | |
FID1 FID2 | 2 | Fiducial | Fiducial:Fiducial_1mm_Mask2mm | ~ | | | - | |
J1 | 1 | 12V | TerminalBlock_Phoenix:TerminalBlock_Phoenix_MKDS-1,5-2-5.08_1x02_P5.08mm_Horizontal | ~ | https://www.tme.eu/sk/details/eb21a-02-d/svorkovnice-do-dps/... | EB21A-02-D | - | WARNING! The cable outlet is turned to the center of the board |
J2 | 1 | AVR-ISP-6 | Connector_PinHeader_2.54mm:PinHeader_2x03_P2.54mm_Vertical | ~ | https://www.tme.eu/sk/details/zl202-6g/konektory-hrebienky/c... | DS1021-2*3SF1-1 | - | |
J3 | 1 | Debug | Connector_PinHeader_2.54mm:PinHeader_1x06_P2.54mm_Vertical | ~ | https://www.tme.eu/sk/details/zl201-06g/konektory-hrebienky/... | DS1021-1*6SF1-1 | - | |
J4 | 1 | OUT | TerminalBlock_Phoenix:TerminalBlock_Phoenix_MKDS-1,5-3-5.08_1x03_P5.08mm_Horizontal | ~ | https://www.tme.eu/sk/details/eb21a-03-d/svorkovnice-do-dps/... | EB21A-03-D | - | WARNING! The cable outlet is turned to the center of the board |
J5 | 1 | 2xFSR | TerminalBlock_Phoenix:TerminalBlock_Phoenix_MKDS-1,5-4-5.08_1x04_P5.08mm_Horizontal | ~ | https://www.tme.eu/sk/details/eb21a-02-d/svorkovnice-do-dps/... | EB21A-04-D | - | WARNING! The cable outlet is turned to the center of the board |
K1 | 1 | G5V-1 | Relay_THT:Relay_SPDT_Omron_G5V-1 | https://omronfs.omron.com/en_US/ecb/products/pdf/en-g5v_1.pd... | https://www.tme.eu/sk/details/g5v1-5/elektromagneticke-rele-... | G5V-1 5VDC | - | |
Q1 | 1 | BC846 | Package_TO_SOT_SMD:SOT-23 | https://assets.nexperia.com/documents/data-sheet/BC846_SER.p... | https://www.tme.eu/sk/details/bc846b-dio/tranzistory-npn-smd... | BC846B | - | |
R4 R6 R1 R2 R3 R5 | 6 | 1k 1% 0805 | Resistor_SMD:R_0805_2012Metric_Pad1.15x1.40mm_HandSolder | ~ | | | - | |
R7 R8 | 2 | 1M 1% 0805 | Resistor_SMD:R_0805_2012Metric_Pad1.15x1.40mm_HandSolder | ~ | | | - | |
SW1 | 1 | DIP SW | Button_Switch_SMD:SW_DIP_SPSTx03_Slide_6.7x9.18mm_W8.61mm_P2.54mm_LowProfile | ~ | https://www.tme.eu/sk/details/esd103ez/prepinace-dip-switch/... | ESD103EZ | - | |
U1 | 1 | L7805 | Package_TO_SOT_SMD:TO-252-2 | http://www.st.com/content/ccc/resource/technical/document/da... | https://www.tme.eu/sk/details/l78m05acdt/stabilizatory-napat... | L78M05ACDT-TR | - | |
U2 | 1 | ATmega328-AU | Package_QFP:TQFP-32_7x7mm_P0.8mm | http://ww1.microchip.com/downloads/en/DeviceDoc/ATmega328_P%... | https://www.tme.eu/sk/details/atmega328pb-au/modelovy-rad-av... | ATMEGA328PB-AU | - | |
Y1 | 1 | 16Mhz | Crystal:Crystal_SMD_3225-4Pin_3.2x2.5mm | https://www.tme.eu/Document/3a91ec8d73b60f9ff7f12b18599fa28b... | https://www.tme.eu/sk/details/16.00m-iqxc-180a/krystalove-re... | LFXTAL053426CUTT | - | |
